Vertical tube furnace
- Product Introduction -
Summary
ALCERA SK14 series vertical tube furnace is a new type product independent developed by ALCERA. It adopts MoSi2 heating element, one area temperature control, B type thermocouple for temperature measurement. Each one K type thermocouple set 50mm away from Top and bottom roof to measure the ceramic tube temperature. Two temperature measurement holes optional set at the central section. It adopts ALCERA independent thermal insulation materials, with unique 3D furnace materials processing technology, electrical components of Schneider, Japanese whole set product appearance, fine process of manufacture and safety performance.
This type tube furnace is suitable for the experiments for the institutions of universities and scientific research departments and industrial and mining enterprises or small batch production, with the characteristics of easy to operate, high precision of temperature control, good effect of heat preservation , large temperature range, high temperature uniformity, etc.
- Technical Parameter -
| Long-term working temperature | 1400 ℃ |
| The highest working temperature | 1450 ℃ |
| Uniform temperature zone length | 150 mm, diameter 60 mm |
| Temperature uniformity | ±3 ℃ |
| Electrical parameters | 220 v, 2 kw |
| Outlook size | 550mm×550mm×680mm |
- Contact Us -
|
Tel:+86-512-63496667-162 Fax:+86-512-63496217 QQ:3262838371 Email:alcera@alcera.cn Wechat:alcera Website:www.alcera.cn Postcode:215200 Add: No.8 Yexin Rd, Wujiang Economic and Technology Development Zone, Jungian, PRC |
ALCERA (SUZHOU) CO., LTD
